TheofficialFAT specification is available from Microsoft, complete with asoftware 'license agreement'. Saddly, the documentfrom Microsoft is hard to read if you do not already understand the FATfilesystem structure, and it lacks information about disk partitioningwhich also must be dealt with to properly use standard hard drives. Whileyou may find the Microsoft spec useful, this page is meant to 'stand alone'...and you can simply read it without suffering through 3 pages of legalese!

However, this page will intentionally 'gloss over' many small detailsand omit many of the finer points, in an attempt to keep it simple andeasy to read for anyone faced with learning FAT32 without any previousexposure.

Where To Start... How About At The Beginning?

The first 446 bytes of the MBR are code that boots the computer.This is followed by a 64 byte partition table, and the last twobytes are always 0x55 and 0xAA. You should always check theselast two bytes, as a simple 'sanity check' that the MBR is ok.

The MBR can only represent four partitions. A technique called 'extended'partitioning is used to allow more than four, and often times itis used when there are more than two partitions. All we're goingto say about extended partitions is that they appear in this tablejust like a normal partition, and their first sector has anotherpartition table that describes the partitions within its space.But for the sake of simply getting some code to work, we're goingto not worry about extended partitions (and repartition and reformatany drive that has them....) The most common scenario is only onepartition using the whole drive, with partitions 2, 3 and 4 blank.

Each partition description is just 16 bytes, and the good news isthat you can usually just ignore most of them. The fifth byte isa Type Code that tellswhat type of filesystem is supposed to be contained within thepartition, and the ninth through twelth bytes indicate the LBABeginaddress where that partition begins on the disk.

Normally you only need to check the Type Code of each entry,looking for either 0x0B or 0x0C (the two that are used for FAT32),and then read the LBA Begin to learn where the FAT32 filesystemis located on the disk.

TODO: add a table of known type codes, with the FAT32 ones colored

The Number of Sectors field can be checked to make sure youdo not access (particularly write) beyond the end of the space thatis allocated for the parition. However, the FAT32 filesystem itselfcontains information about its size, so this Number of Sectorsfield is redundant. Several of Microsoft's operating systems ignoreit and instead rely on the size information embedded within the firstsector of the filesystem. (yes, I have experimentally verified this,though unintentionally :)Linux checks the Number of Sectors field and properly preventsaccess beyond the allocated space. Most firmware will probably ignore it.

The Boot Flag, CHS Begin, and CHS End fields should be ignored.

FAT32 Volume ID... Yet Another First Sector

Microsoft's specification lists many variables, and the FAT32Volume ID is slightly different than the older ones used for FAT16and FAT12. Fortunately, most of the information is not neededfor simple code. Only four variables are required, and threeothers should be checked to make sure they have the expected values.

After checking the three fields to make sure the filesystem is using512 byte sectors, 2 FATs, and has a correct signature, you may want to'boil down' these variables read from the MBR and Volume ID into justfour simple numbers that are needed for accessing the FAT32 filesystem.Here are simple formulas in C syntax:

As you can see, most of the information is needed only to learn thelocation of the first cluster and the FAT. You will need to rememberthe size of the clusters and where the root directory is located, butthe other information is usually not needed (at least for simply readingfiles).

If you compare these formulas to the ones in Microsoft's specification,you should notice two differences. They lack 'RootDirSectors', becauseFAT32 stores the root directory the same way as files and subdirectories,so RootDirSectors is always zero with FAT32. For FAT16 and FAT12, thisextra step is needed to compute the special space allocated for the rootdirectory.

Microsoft's formulas do not show the 'Partition_LBA_Begin' term. Theirformulas are all relative to the beginning of the filesystem, which theydon't explicitly state very well. You must add the 'Partition_LBA_Begin'term found from the MBR to compute correct LBA addresses for the IDEinterface, because to the drive the MBR is at zero, not the Volume ID.Not adding Partition_LBA_Begin is one of the most common errors mostdevelopers make, so especially if you are using Microsoft's spec, do notforget to add this for correct LBA addressing.

The rest of this page will usually refer to 'fat_begin_lba', 'cluster_begin_lba','sectors_per_cluster', and 'root_dir_first_cluster', rather than theindividual fields from the MBR and Volume ID, because it is easiest tocompute these numbers when starting up and then you no longer need all thedetails from the MBR and Volume ID.

How The FAT32 Filesystem Is Arranged

The vast majority of the disk space is the clusters section,which is used to hold all the files and directories. Theclusters begin their numbering at 2, so there is no cluster #0or cluster #1. To access any particular cluster, you need touse this formula to turn the cluster number into the LBA addressfor the IDE drive:

lba_addr = cluster_begin_lba + (cluster_number - 2) * sectors_per_cluster;

Normally clusters are at least 4k (8 sectors), and sizes of 8k, 16k and32k are also widely used. Some later versions of Microsoft Windows allowusing even larger cluster sizes, by effectively considering the sectorsize to be some mulitple of 512 bytes. The FAT32 specification fromMicrosoft states that 32k is the maximum cluster size.

Now If Only We Knew Where The Files Were....

In this section, we'll only briefly look at directories as much asis necessary to learn where the files are, then we'll look at howto access the rest of a file using the FAT,and later we'll revisit directory structure in more detail.

Directory data is organized in 32 byte records. This is nice, becauseany sector holds exactly 16 records, and no directory record will evercross a sector boundry. There are four types of 32-byte directoryrecords.

1. Normal record with short filename - Attrib is normal
2. Long filename text - Attrib has all four type bits set
3. Unused - First byte is 0xE5
4. End of directory - First byte is zero

Records that do not begin with 0xE5 or zero are actual directory data, andthe format can be determined by checking the Attrib byte. For now, we areonly going to be concerned with the normal directory records that havethe old 8.3 short filename format. In FAT32, all files and subdirectorieshave short names, even if the user gave the file a longer name, so you canaccess all files without needing to decode the long filename records (as longas your code simply ignores them). Here is the format of a normaldirectory record:

The Attrib byte has six bits defined, as shown in the table below. Mostsimple firmware will check the Attrib byte to determine if the 32 bytes area normal record or long filename data, and to determine if it is a normalfile or a subdirectory. Long filename records have all four of the leastsignificant bits set. Normal files rarely have any of these four bits set.

The remaining fields are relatively simple and straigforward.The first 11 bytes are the short filename (old 8.3 format). The extensionis always the last three bytes. If the file's name is shorter than 8 bytes,the unused bytes are filled with spaces (0x20). The starting cluster numberis found as two 16 bit sections, and the file size (in bytes) is found in thelast four bytes of the record. In both, the least significant byte is first.The first cluster number tells you where the file's data begins on the drive,and the size field tells you how long the file is The actual space allocatedon the disk will be an integer number of clusters, so the file size lets youknow how much of the last cluster is the file's data.

File Allocation Table - Following Cluster Chains

The File Allocation Table is a big array of 32 bit integers, where eachone's position in the array corresponds to a cluster number, and thevalue stored indicates the next cluster in that file. The purpose ofthe FAT is to tell you where the next cluster of a file is located onthe disk, when you know where the current cluster is at. Every sector ofof the FAT holds 128 of these 32 bit integers, so looking up the nextcluster of a file is relatively easy. Bits 7-31 of the current clustertell you which sectors to read from the FAT, and bits 0-6 tell you whichof the 128 integers in that sector contain is the number of the nextcluster of your file (or if all ones, that the current cluster is the last).

Here is a visual example of three small files and a root directory, allallocated near within first several clusters (so that one one sector ofthe FAT is needed for the drawing). Please note that in this example,the root directory is 5 clusters... a very unlikely scenario for a drivewith only 3 files. The idea is to show how to follow cluster chains, butplease keep in mind that a small root directory (in only 1 cluster) wouldhave 'FFFFFFFF' at position 2 (or whereever the volume ID indicated asthe first cluster), rather than '00000009' leading to even more clusters.However, with more files, the root directory would likely span severalclusters, and rarely would a root directory occupy consecutive clustersdue to all the allocation for files written before the directory grew touse more clusters. With that caveat in mind, here's that simple example:

In this example, the root directory begins at cluster 2, which is learnedfrom the Volume ID. The number at position 2 in the FAT has a 9, so thesecond cluster is #9. Likewise, clusters A, B, and 11 hold the remainderof the root directory. The number at position 11 has 0xFFFFFFFF whichindicates that this is the last cluster of the root directory. Inpractice, your code may not even attempt to read position 11 because thean end-of-directory marker (first of 32 bytes is zero) would be found.Likewise, a filesystem with a small root directory might fit entirelyinto one cluster, and the FAT could not be needed at all to read such adirectory. But if you reach the end of the 32 byte entries within thefirst cluster without finding the end-of-directory marker, then the FATmust be used to find the remaining clusters.

Similarly, three files are shown. In each case, the FAT gives noindication of which cluster is the first... that must be extracted fromthe directory, and then the FAT is used to access subsequent clustersof the file. The number of clusters allocated to the file shouldalways be enough to hold the number of bytes specified by the sizefield in the directory. A portion of the last cluster will be unused,except in the rare case where the file's size is an exact multiple ofthe cluster size. Files that are zero length do not have any clustersallocated to them, and the cluster number in the directory should be zero.Files that fit into just one cluster will have only the 'FFFFFFFF'end of file marker in the FAT at their cluster position.

Shortcut Hint: One approach to the simplest possible code is to keepthe root directory very small (few files, only 8.3 filenames), avoidsubdirectories, and runthe 'defrag' program on a PC. That way, the root directory is found injust one cluster and every file occupies only consecutive clusters.Though this approach is very limiting, it means you can read fileswithout using the FAT at all.

According to Microsoft's spec, the cluster numbers are really only 28 bitsand the upper 4 bits of a cluster are 'reserved'. You should clear thosetop for bits to zeros before depending on a cluster number. Also, theend-of-file number is actually anything equal to or greater than 0xFFFFFFF8,but in practive 0xFFFFFFFF is always written. Zeros in the FAT markclusters that are free space. Also, please remember that the clusternumbers are stored with their least significant byte first (Figure 7shows them human-readable formatted, but they are actually stored LSB first).

The good news for a firmware designer working with limited resources isthat FAT is really very simple. However, FAT's simplicity is also itsweakness as a general purpose file system for high performance computing.For example, to append data to a file, the operating system must traversethe entire cluster chain. Seeking to random places within a file alsorequires many reads within the FAT. For the sake of comparison,unix filesystems use a tree-likestructure, where a cluster (also called a 'block') has either a list ofblocks (often called 'inode' in unix terminology), or a list of otherinodes which in turn point to blocks. In this manner, the location ondisk of any block can be found by reading 1, 2, or 3 (for huge files)inodes. The other weakness of FAT, which is mitigated by caching, isthat it is physically located near the 'beginning' of the disk, ratherthan physically distributed. Unix inode-based filesystems scatter theinode blocks evenly among the data blocks, and attempt to describe thelocation of data using nearby inode blocks.

Directories and Long Filenames In Detail

TODO: write this section someday.... the basic idea is that a bunch of32-byte entries preceeding the normal one are used to hold the long namethat corresponds to that normal directory record.

Where's the Free Code ???

However, you can find FAT32 code in the mp3 player project.The 0.1.x and 0.5.x firmware used a simple one-sector-at-a-time approachthat is very easy to understand and only needs a single 512 byte buffer,but is not very sophisticated. These old firmware revs do not properlyfollow cluster chains for file (they do for directories), so it is necessaryto run defrag before using the drive with them.

The 0.6.x mp3 player firmware does use the FAT properly to follow clusterchains. It uses megabytes of memory from the SIMM to buffer cluster andsectors from the FAT. A table of recently read FAT sectors is maintained,and a binary search is implemented to quickly locate the memory associatedwith any cached FAT sector. The firmware manages the megabytes of RAM bydividing it into 4k chunks (which works together with the bank swappingimplemented by the FPGA), and the first 32 hold a big array of 16-bytestructs with info about what is held in each 4k block. These structsimplement linked lists that for each file cached in memory. A file I/OAPI is built on top of this to allow the main program to access the cacheddata. The 0.6.x firmware also uses DMA, so data transfers are quite fast.

Both of the MP3 player project FAT32 implementations are read-only. Bothare GPL'd, but both are quite specific to that project. You can chooseeither very simple without features and needing defrag, or quite complexwith lots of features but heavily dependent on the FPGA and SIMM.

Perhaps someday I will write a more general purpose FAT32 implementationwith nice documentation for this code library section. But this is notplanned for the near future. Hopefully the description on this pagewill at least help you to understand how FAT32 works so you can writeyour own code or understand the project-specific code in the mp3 players.

Other Sites With FAT Filesystem Code For Microcontrollers

• Rob's Projects - FAT32 File I/O Library. Intended for AVR, but the code is in C.
• Nassif's ZipAmp - A mp3 player with FAT16 and FAT32 code.

Please Help....

Understanding FAT32 can be difficult, especially if you can only findpoorly written documentation like Microsoft's specification. I wrotethis page to help bridge the gap and make understanding FAT32 easier.Please help make it easier for others to find it.
